CJ Series Jaw Crusher

CJ Series Jaw Crusher

It is used as the first process to crush all kinds of rocks with less than 320MPa compressive strength into medium particle size one time.

120-1590t/h Production Capacity

≤1000mm Feed size

contact us


Production Introduction

CJ series European version jaw crusher is commonly used for primary or secondary crushing in the mining material crushing. It is advanced equipment developed for the crushing of construction materials in highway, railway, airport runway and other projects. It can also be used for secondary and fine crushing of various hard ores and rocks in metallurgy, mining, chemical, cement, construction, refractory, ceramics and other industrial sectors. Compared with the traditional secondary jaw crusher, European version of jaw crusher shows its unparalleled superiority at the aspects of service life, maintenance rate and failure rate.

For details

The Main Benefits and Advantages:

Unique structure

Operation cost is low

1. It adopts world-class manufacturing process and the most high-end materials.

2. Equipped with wedged adjustment device of discharge port, it is easier, safer and quicker to adjust than the old-type gasket.

For details

Easy operation

High degree of automation

CJ series European Version jaw crusher is a kind of jaw crusher with excellent performance introduced and developed by our company. It has advantages of small footprint, higher crushing ratio, more stable operation, easy transportation and installation, maintenance and adjustment. So it is particularly suitable for fixed crushing production line and mobile crushing station.


CJ Series Jaw CrusherTechnical Parameter

TO VIEW MORE
Model Maximum Feeding size(mm) Feeding opening size L×W(mm) Adjustment range of discharge port(mm) Capacity(t/h) Power(KW) Dimensions L×W×H(mm)
CJ96 480 930×580 60-175 105-390 4P 90 2850×2270×1950
CJ106 560 1060×700 70-200 150-500 4P 110 3280×2580×2400
CJ120 700 1200×870 70-200 175-610 4P 160 3700×2790×2950
CJ125 760 1250×950 100-250 270-831 4P 160 4230×2780×2960
CJ150 960 1400×1200 125-250 340-880 4P 200 5030×3440×3970
CJ160 960 1600×1200 150-300 430-1145 4P 250 5780×3460×3580
CJ200 1200 2000×1500 175-300 630-1590 6P 400 6600×3000×4400
CJ1511 850 1500×1070 125-300 380-1080 6P 200 4130×3000×3330
CJ1513 1040 1500×1300 150-300 480-1160 6P 200 4620×2890×4190

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
