Fine Sand Recycling Machine

Fine Sand Recycling Machine

Sand Pump Power: 11-55Kw

30-650m³/h Processing Water Volume

250-900mm Separator Spec

contact us

Fine Sand Recycling Machine

Product Description

The fine sand recovery machine separates the slurry with the concentration≤40% into the hydrocyclone separator through the slurry pump, and the separated coarse fraction enters the dehydration flash sieve for dehydration recovery. Maximize the recovery of materials above 75cm, remove sludge and clay below 75cm, can be used with the sand washing machine on the existing production line, or can be used alone to improve resource utilization and maximize revenue.

For details

Our Company

The company is headquartered in Zhengzhou High-tech Industrial Development Zone, Henan Province, China, covering a total area of 350,000 square meters, with 260,000 square meters of standardized heavy industrial plants, more than 600 large and medium-sized processing, riveting and assembly equipment, online employees More than 2,300 people, including the level and title of management cadres and engineering and technical personnel more than 400 people.

For details
Fine Sand Recycling Machine

Fine Sand Recycling MachineTechnical Parameter

TO VIEW MORE
Model Sand Pump
Power (kw)
Sepatator Spec
(mm)
Dewatering Screen Processing Water
Volume (m3/h)
Specifications
(mm)
Power
(kw)
FTM-250 11 250 800×2000 2×0.75 30-60
FTM-300 15 300 800×2000 2×0.75 60-100
FTM-350 18.5 350 1000×2000 2×1.5 70-130
FTM-550 22 550 1200×3000 2×2.2 100-220
FTM-650 30 650 1500×3000 2×3 120-272
FTM-750 37 750 1500×3000 2×3 180-350
FTM-750(Ⅱ) 45 750 1800×3600 2×4 230-430
FTM-900 55 900 1800×3600 2×4 450-650
