HD German Type Jaw Crusher

HD German Type Jaw Crusher

Applied Materials: pebble, granite, basalt, iron ore, limestone, quartz stone, dolerite, gold ore, copper ore, etc.

85-650t/hHandling Capacity

≤800mmFeeding Size

contact us

HD Jaw Crusher

Production Introduction

The HD German type jaw crusher has been designed optimally in crushing cavity type and motion parameter, which increases the output and quality of the machine and enlarges its application range. It can be widely used in many industries, such as metallic ores and non-metallic ores, construction, gravel, cement, metallurgy, etc. It performs excellently in processing hard materials.

For details

Working Principle

In mining and building crushing industries, the property of the jaw crusher, as the primary crushing machine, has an influence on the quality and running situation of the whole production line, which makes people have increasing high requirements in the capacity and stability of the jaw crusher. To meet the demand in the market, we, Fote Heavy Machinery, with several years’ experience, have developed the HD German type jaw crusher with the German crushing machinery experts, achieving a new breakthrough in mining and gravel production line.

For details
HD Jaw Crusher

Properties of HD German Type Jaw Crusher

1. High production efficiency, higher productivity

2. Humanized design, convenience in the operation

3. Reasonable design, good quality

4. Wide application range, high adaptability

HD Jaw Crusher

HD German Type Jaw CrusherTechnical Parameter

TO VIEW MORE
Model Feeding opening size(mm) Max.Feeding size (mm) Adjustment range of discharge port(mm) Capacity(t/h) Power(kw) Dimensions L×W×H (mm)
HD72(57) 460×720 425 45-100 50-120 6P   55 2100×1556×1640
HD86(69) 580×860 500 50-150 60-280 8P   75 2200×1754×1810
HD98(751) 680×980 630 75-175 110-410 8P   110 2660×1960×2175
HD110(912) 850×1100 750 100-200 230-550 6P   132 2960×2381×2556
HD125 950×1250 900 125-225 280-750 8P   160 3500×2614×2925

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
