Jaw crusher is the earliest crusher for primary and secondary crushing, and it can save 15%-30% power energy consumption.
CONTACT USJaw crusher has many advantages, such as big crushing ratio, equal product granularity, simple structure, reliable working condition, convenient repair and economical operation. They are widely used in the works of mine, smelting, building material, road, railway, irrigation, chemical industry, etc. The compression strength of the materials to be crushed is less than 320 MPA.
High quality steel plate invoids the defects of casted steel making the whole frame more stable
Reduce vibration effectively; Machines work more stably
Discharging outlet dash adjusting easily and reliable. Convenient maintenance.
Deep crushing chamber and no dead space, increase the feeding capability and capacity with big crushing ratio and even particle size.
A super-large-scaled modern green industrial workshop 260000 square meters, large and medium-sized gold processing, maohan, assembly equipment more than 600 sets.
CONTACT US
| Model | Feeding opening size(mm) | Max.Feeding Size(mm) | Adjustment range of Discharge Opening(mm) | Processing Capacity (t/h) | Eccentric shaft speed(r/min) | Power (kw) | Dimensions(L×W×H) (mm) |
| PE 150×250 | 150×250 | 125 | 10-40 | 1-3 | 268 | 4P 5.5 | 760×700×860 |
| PE 200×300 | 200×300 | 180 | 15-50 | 2-6 | 260 | 4P 7.5 | 920×790×980 |
| PE 200×350 | 200×350 | 180 | 18-60 | 3-10 | 276 | 4P 11 | 1000×920×1115 |
| PE 250×400 | 250×400 | 210 | 20-70 | 5-21 | 300 | 6P 15 | 1110×1070×1290 |
| PE 400×600 | 400×600 | 340 | 40-100 | 16-64 | 270 | 6P 30 | 1630×1740×1613 |
| PE 500×750 | 500×750 | 425 | 50-100 | 40-110 | 268 | 6P 55 | 1916×1848×1920 |
| PE 600×750 | 600×750 | 500 | 150-200 | 80-240 | 268 | 6P 55 | 2020×1848×1920 |
| PE 600×900 | 600×900 | 500 | 65-150 | 70-180 | 254 | 6P 55 | 2540×2000×2345 |
| PE 750×1060 | 750×1060 | 630 | 80-180 | 110-320 | 245 | 8P 110 | 2680×2380×2785 |
| PE 900×1200 | 900×1200 | 750 | 100-200 | 220-380 | 208 | 8P 110 | 3480×2910×3330 |
| PE 1200×1500 | 1200×1500 | 1020 | 150-350 | 400-1000 | 20 | 8P 245 | 5000×3222×3843 |
| PE 1500×1800 | 1500×1800 | 1200 | 220-350 | 580-1200 | 200 | 8P 380 | 5682×3940×5335 |
| PEX 150×750 | 150×750 | 120 | 18-50 | 8-25 | 320 | 4P 15 | 1170×1580×1030 |
| PEX 250×750 | 250×750 | 210 | 25-60 | 13-35 | 320 | 6P 22 | 1550×1730×1470 |
| PEX 250×1000 | 250×1000 | 210 | 25-60 | 16-52 | 330 | 6P 30 | 1590×2010×1380 |
| PEX 250×1200 | 250×1200 | 210 | 25-60 | 20-61 | 330 | 6P 37 | 1780×2220×1430 |
| PEX 300×1300 | 300×1300 | 250 | 20-90 | 16-105 | 300 | 6P 55 | 2210×2320×1725 |
| PEX 500×1500 | 500×1500 | 420 | 25-100 | 50-180 | 28C | 6P 90 | 2430×2560×2020 |
Note: The motor power in the above table is suitable for 50HZ. When the power supply is 60HZ, the motor poles for PE150×250 and PEX150×750 change to 6 poles.
Note: Processing capacity may vary with different materials and feeding sizes.
| Model | Feeding opening size(mm) | Max.Feeding Size(mm) | Processing Capacity (t/h) |
| PE 150×250 | 150×250 | 125 | 1-3 |
| PE 200×300 | 200×300 | 180 | 2-6 |
| PE 200×350 | 200×350 | 180 | 3-10 |
| PE 250×400 | 250×400 | 210 | 5-21 |
| PE 400×600 | 400×600 | 340 | 16-64 |
| PE 500×750 | 500×750 | 425 | 40-110 |
| PE 600×750 | 600×750 | 500 | 80-240 |
| PE 600×900 | 600×900 | 500 | 70-180 |
| PE 750×1060 | 750×1060 | 630 | 110-320 |
| PE 900×1200 | 900×1200 | 750 | 220-380 |
| PE 1200×1500 | 1200×1500 | 1020 | 400-1000 |
| PE 1500×1800 | 1500×1800 | 1200 | 580-1200 |
| PEX 150×750 | 150×750 | 120 | 8-25 |
| PEX 250×750 | 250×750 | 210 | 13-35 |
| PEX 250×1000 | 250×1000 | 210 | 16-52 |
| PEX 250×1200 | 250×1200 | 210 | 20-61 |
| PEX 300×1300 | 300×1300 | 250 | 16-105 |
| PEX 500×1500 | 500×1500 | 420 | 50-180 |
Note: The motor power in the above table is suitable for 50HZ. When the power supply is 60HZ, the motor poles for PE150×250 and PEX150×750 change to 6 poles.
Note: Processing capacity may vary with different materials and feeding sizes.
| Model | Feeding opening size(mm) | Max.Feeding size （mm） | Adjustment range of discharge port（mm） | Capacity(t/h) | Power(kw) | Dimensions L×W×H （mm） |
| HD72(57) | 460×720 | 425 | 45-100 | 50-120 | 6P 55 | 2100×1556×1640 |
| HD86(69) | 580×860 | 500 | 50-150 | 60-280 | 8P 75 | 2200×1754×1810 |
| HD98(751) | 680×980 | 630 | 75-175 | 110-410 | 8P 110 | 2660×1960×2175 |
| HD110(912) | 850×1100 | 750 | 100-200 | 170-550 | 6P 132 | 2960×2381×2556 |
| HD125 | 950×1250 | 900 | 125-225 | 280-750 | 8P 160 | 3500×2614×2925 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
| Model | Feeding opening size(mm) | Max.Feeding size（mm） | Capacity (t/h) |
| HD72(57) | 460×720 | 425 | 50-120 |
| HD86(69) | 580×860 | 500 | 60-280 |
| HD98(751) | 680×980 | 630 | 110-410 |
| HD110(912) | 850×1100 | 750 | 170-550 |
| HD125 | 950×1250 | 900 | 280-750 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
| Model | Feeding opening size(mm) | Maximum Feeding Size(mm) | Adjustment range of discharge port(mm) | Processing capacity(t/h) | Power (kw) | Dimensions (L×W×H)(mm) |
| CJ80 | 800×510 | 410 | 40-175 | 55-335 | 4P 75 | 2660×2162×1800 |
| CJ96 | 930×580 | 480 | 60-175 | 105-390 | 4P 90 | 2850×2180×1990 |
| CJ100 | 1000×760 | 600 | 70-200 | 150-420 | 4P 110 | 3535×2350×2510 |
| CJ106 | 1060×700 | 560 | 70-200 | 150-500 | 4P 110 | 3280×2510×2400 |
| CJ116 | 1150×760 | 608 | 70-200 | 165-520 | 4P 132 | 3840×2440×2650 |
| CJ120 | 1200×870 | 700 | 70-200 | 175-610 | 4P 160 | 3700×2790×2950 |
| CJ125 | 1250×950 | 760 | 100-250 | 240-800 | 4P 160 | 4230×2820×3080 |
| CJ130 | 1300×1000 | 800 | 100-250 | 270-831 | 4P 185 | 4220×2810×3330 |
| CJ150 | 1400×1200 | 960 | 125-250 | 340-880 | 4P 200 | 5040×3445×3970 |
| CJ160 | 1600×1200 | 960 | 150-300 | 430-1145 | 4P 250 | 5780×3460×3840 |
| CJ180 | 1800×1200 | 960 | 150-300 | 485-1290 | 6P 315 | 5640×3780×3920 |
| CJ200 | 2000×1500 | 1200 | 175-300 | 630-1435 | 6P 400 | 6600×4040×4580 |
Note: Processing capacity may vary with different materials and feeding sizes.
| Model | Feeding opening size(mm) | Maximum Feeding Size(mm) | Processing capacity(t/h) |
| CJ80 | 800×510 | 410 | 55-335 |
| CJ96 | 930×580 | 480 | 105-390 |
| CJ100 | 1000×760 | 600 | 150-420 |
| CJ106 | 1060×700 | 560 | 150-500 |
| CJ116 | 1150×760 | 608 | 165-520 |
| CJ120 | 1200×870 | 700 | 175-610 |
| CJ125 | 1250×950 | 760 | 240-800 |
| CJ130 | 1300×1000 | 800 | 270-831 |
| CJ150 | 1400×1200 | 960 | 340-880 |
| CJ160 | 1600×1200 | 960 | 430-1145 |
| CJ180 | 1800×1200 | 960 | 485-1290 |
| CJ200 | 2000×1500 | 1200 | 630-1435 |
Note: Processing capacity may vary with different materials and feeding sizes.
